K9
Sino Star
Availability: | |
---|---|
Quantity: | |
Model | K9 |
Power Supply | 380V/50Hz/3Ph 40KW |
Min. Installation Sizes(mm) | 7000*3500*3200mm L*W*H |
Max. Vehicle Sizes(mm) | 5600*2600*2050mm L*W*H |
Rail Length(mm) | 7000mm |
Shipping Weight/Volume | 1900kg/10m3 |
Guarantee | 3 Years Warranty |
Water Pump Motor Power(kw) | 380V/15KW |
Air Fan Motor Power(kw) | 5.5KW*4pcs |
Water Pressure | 60-100bar |
Rinse a circle | 30seconds |
Car Wash Time(min) | 2~5Minutes/car |
Water Consumption(L) | 80-150L/car |
Chemical Consumption(ml) | 20-50ml/car |
Electricity Consumption(Degree) | 0.3-0.8degree/car |
CPU | Embedded CPU Industrial control |
Longitudinal/Transversal /Rotate | Inverter Drive |
Vehicle Detection System | Ultrasonic and encoder |
Chemical Mixing System | Metering pump automatic proportioning |
Anti-collision System | Electronic Anti-collision System |
Lighting system | Main light+gradient light |
360-degree rotating Rinse | 304 stainless steel swivel arm Up and down ectopic flushing |
Chemical Mixing System Small Water Pump | 304 stainless steel pump |
Sheet Metal Process | Automotive Grade Process Electrophoretic Coating |
Self -service parking system | Voice LED arrow prompt guidance |
Under chassis wash system | 304 stainless steel |
Mounting Frames | 100*100*4 Hot Dip Galvanized |
