| Model | SS-DC-020-B-A-O-4 | SS-DC-30-B-A-O-4 | SS-DC-40-B-A-O-4 |
| Installation Method | Wall mounted / Floor stand mounted | Wall mounted / Floor stand mounted | Wall mounted / Floor stand mounted |
| Product size (mm) | 482*660*240 (mm) | 482*660*240 (mm) | 482*660*240 (mm) |
| INPUT |
|
|
|
| Voltage | AC380V ± 15% | AC380V ± 15% | AC380V ± 15% |
| Input frequency | 50/60Hz | 50/60Hz | 50/60Hz |
| Single Gun Output Current Range | 0-80 A | 0-80 A | 0-80 A |
| OUTPUT |
|
|
|
| Voltage | 200-1000 VDC | 200-1000 VDC | 200-1000 VDC |
| Rated power KW | 20kW | 30kW | 40kW |
| Charging cable length | 5m (according to the requirements) | 5m (according to the requirements) | 5m (according to the requirements) |
| Accuracy | Level 1.0 | Level 1.0 | Level 1.0 |
| Electrical Specification |
|
|
|
| Current Limit Protection Value | ≥110% | ≥110% | ≥110% |
| Voltage Stabilization Accuracy | ≤±0.5% | ≤±0.5% | ≤±0.5% |
| Current Stabilization Accuracy | ≤±1% | ≤±1% | ≤±1% |
| Ripple Ratio | ≤±0.5% | ≤±0.5% | ≤±0.5% |
| Efficiency | ≥95% | ≥95% | ≥95% |
| Power Factor | ≥0.99 (above 50% load） | ≥0.99 (above 50% load） | ≥0.99 (above 50% load） |
| Harmonic Content THD | ≤5% (above 50% load） | ≤5% (above 50% load） | ≤5% (above 50% load） |
| RCD | / | / | / |
| Functional Design |
|
|
|
| Human-computerinteraction | 4.3- inch highlight color touch screen | 4.3- inch highlight color touch screen | 4.3- inch highlight color touch screen |
| Charge mode | Automatic charging full / Fixed power / Fixed Amount / Fixed time | Automatic charging full / Fixed power / Fixed Amount / Fixed time | Automatic charging full / Fixed power / Fixed Amount / Fixed time |
| Charging method | Swipe card / Password | Swipe card / Password | Swipe card / Password |
| Payment Methods | Credit card / Password | Credit card / Password | Credit card / Password |
| Networking methods | Ethernet | Ethernet | Ethernet |
| Executive standards | IEC 61851-1:2017,ICE 62196-2:2016 | IEC 61851-1:2017,ICE 62196-2:2016 | IEC 61851-1:2017,ICE 62196-2:2016 |
| EVSE to Backend | OCPP1.6J | OCPP1.6J | OCPP1.6J |
| Environmental Indicators |
|
|
|
| Working Temperature | -20℃ ~ +50℃ | -20℃ ~ +50℃ | -20℃ ~ +50℃ |
| Working Humidity | 5%~95% non-condensing frost | 5%~95% non-condensing frost | 5%~95% non-condensing frost |
| Working Altitude | ＜2000m | ＜2000m | ＜2000m |
| Ingress Protection | IP54 | IP54 | IP54 |
| Cooling Method | Air-cooled | Air-cooled | Air-cooled |
| Noisy Control | ≤60dB | ≤60dB | ≤60dB |
| MTBF | 17520 hours | 17520 hours | 17520 hours |
